Universal OBD V1.5 ELM327OBD2 Bluetooth AutoScanner OBDII 2 Car ELM 327 Tester Diagnostic Tool for Android Windows

Description

Top Reason to Choose V1.5 Hardware:

1. PICI8F25K80 Chip, real ELM327 1.5 version support 9 protocol include SAE-J1850 PWM , JAE J1850 VPW(for F-ord old cars and for G M old cars use this protocol like Explorer 1998 )
2. Higher Quality. Say NO to poor quality , Save your time and money!
3. More support , provide useful app for ELM327 Like TORQUE
4. If you need ELM327 Wifi, pls check it here: ELM327 WIFI Support IOS
5. If the CD is broken,pls download software from: 360diag.net . sorry for the inconvenience to you,please never open a dispute before contact with the seller.

Highlights:
The newly developed wireless scan tool.
It supports almost OBD-II protocols.
Bluetooth connection, no Batteries, Cables, or Switches.
Wireless (Bluetooth) 5~10 meter
Retrieve Fault Codes (DTCs) and clear Check Engine lights.
Can also be used with a PC with a Bluetooth Card.

Features:
Read diagnostic trouble codes, both generic and manufacturer-specific , and display their meaning (over 3000 generic code definitions in the database).
Clear trouble codes and turn off the MIL (“Check Engine” light)
Set the maximum number of responses to obtain
Remove spaces from ECU responses (to speed data transmission)
Store a unique identifier in EEPROM
Set the CAN mask and filter with one command
Easily switch between variable and fixed CAN message lengths
Send CAN remote frames (RTRs)

Display current sensor data, including:
Engine RPM
Calculated Load Value
Coolant Temperature
Fuel System Status
Vehicle Speed
Short Term Fuel Trim
Long Term Fuel Trim
Intake Manifold Pressure
Timing Advance
Intake Air Temperature
Air Flow Rate
Absolute Throttle Position
Oxygen sensor voltages/associated short term fuel trims
Fuel System status
Fuel Pressure
Many others…

Multi-Protocol Support:
1.SAE J1850 PWM(41.6Kbaud)
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings(user adjustable)

Vehicle Coverage:
Works on all OBD2 Vehicles (1996 onwards in USA) and EOBD vehicles ( Petrol cars from 2001 and diesel cars from 2003/2004 in Europe)

For your information:
For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant.

Alfa Romeo/ Audi/ Bentley/ B*M*W/ C-adillac/ C-hevrolet/ Chrysler/ C-itroen/ Daewoo/ F-iat/ F-ord/ G-M/ Hond*a/ H-yundai/ Isuzu/ J-aguar/ J-eep/ Kia/ Landover/ L-exus/ M-azda/ Mercury/ Mini/ N-issan/ M-itsubishi/ Opel/ P-eugeot/ Renault/ Rover/ Saab/ Seat/ Sk-oda/ T-oyota/ Vauxhall/ V-olvo/ VW

This hardware can match many other software still!But most of them are not free!

Works for Windows98/ME/2000/XP/Vista &  7 !
This tool does not match abs and airbag system!
Bluetooth paircode: 1234

Packing List:
A.1*Mini ELM327 Bluetooth Diagnostic Interface
B. 1*CD-ROM
