3D Printer Controller RAMPS 1.4
RepRap Mega Pololu Shield, or RAMPS for short. It is designed to fit the entire electronics needed for a RepRap in one small package for low cost. RAMPS interfaces an Ard Mega with the powerful Ard MEGA platform and has plenty room for expansion. The modular design includes plug in stepper drivers and extruder control electronics on an Ard MEGA shield for easy service, part replacement, upgrade-ability and expansion. Additionally, a number of Ard expansion boards can be added to the system as long as the main RAMPS board is kept to the top of the stack.
Version 1.4 uses surface mount capacitors and resistors to further cover edge issue cases.
Mega 2560 control board:
the board is an ATmega2560 as core microcontroller development board itself has 54 groups digital I / O input / output terminal (14 groups do PWM outputs), 16 sets of simulation than the input side, group 4 UARTs (hardware serial ports), using the 16 MHz crystal oscillator. With the bootloader, download the program directly via USB without having to go through other external writer. Supply part of the optional USB power, or as an external power using the AC-to-DC adapter and battery. Development IDE interface is based on open-source principles, allows you to free download for use in project work, school teaching, motor control, interactive works.
A4988 driver module:
A4988 Stepper Motor Driver Board is a breakout board for Allegro’s A4988 DMOS Microstepping Driver with Translator and Overcurrent Protection; please read the A4988 datasheet carefullybefore using this product.
Warning: Connecting or disconnecting a stepper motor while the driver is powered can destroy the driver. (More generally, rewiring anything while it is powered isasking for trouble.)
Maximum output current is 1A
Simple step and direction control interface
Five different step resolutions: full-step, half-step, quarter-step, eighth-step, and sixteenth-step
Adjustable current control lets you set the maximum current output with a potentiometer,which lets you use voltages above your stepper motor’s rated voltage toachieve higher step rates
Intelligent chopping control that automatically selects the correct current decay mode (fast decay or slow decay)
Over-temperature thermal shutdown, under-voltage lockout, and crossover-current protection
Short-to-ground and shorted-load protection
1Pcs mega 2560 R3
1Pcs Ramps 1.4 with pins jumpers
4Pcs A4988 module with
4Pcs Heat sink
